Skyjack 3219 Scissor Lift Electric

Detailed Description

• Drivable at full height with roll out deck fully extended
• Variable speed, front two wheel hydraulic drive
• 90° Steering (zero inside turning radius)
• Dual holding brakes
• Proportional controls for drive & lift functions
• 0.91 m Roll out extension deck
• 24V DC Power source
• Low voltage battery protection
• Relay-based control system
• SKYCODEDTM Colour coded and numbered wiring system
• Solid rubber, non-marking tyres
• Pothole protection system
• Wiring for AC outlet on platform
• Tilt alarm with drive & lift cut-out
• Overload sensing system
• Lowering warning system
• Operator horn
• Half height spring hinged gate
• Hinged railing system
• Lanyard attachment points
• Forklift pockets and tie down/lift lugs

To book this machine you MUST have hired in plant insurance.   Our insurance policy covers for accidental damage and total loss up to £100,000. There is an insurance excess of £500 per claim. Please speak to one of our advisers if you require further information.

If you wish to arrange your own plant insurance or already have your own policy running that’s fine, if you could please email proof of insurance prior to delivery to sales@kent-hire.co.uk and our insurance cost can be refunded.

Technical Specification

• Manufacture
  Skyjack
• Model
  3219
• Weight
  1312Kg
• Work Height
  7.79m
• Raised Platform Height
  5.79m
• Lowered Platform Height
  0.99m
• Overall Width
  0.81m
• Overall Length
  1.78m
• Stowed Height (Rails Up)
  2.10m
• Stowed Height (Rails Down)
  1.75m
• Platform Width (Inside Dimension)
  0.66m
• Platform Length (Inside Dimension)
  1.63m
• Extension Deck (Roll Out)
  0.91m
• Ground Clearance (Stowed)
  6.03cm
• Ground Clearance (Raised)
  1.78cm
• Wheelbase
  1.40m
• Gradeability
  25%
• Turning Radius (Outside)
  1.68m
• Lift Time (With Rated Load)
  25 sec
• Lower time (With Rated Load)
  29 sec
• Drive Speed (Stowed)
  3.1KM/H
• Drive Speed (Raised)
  1.1KM/H
• Maximum Drive Height
  Full Height
• Capacity (Overall)
  227KG
• Distributed Capacity (Main Platform)
  114KG
• Distributed Capacity (Extension Deck)
  113KG
• Local Floor Load (With Rated Load)
  782kPa
• Overall Floor Load (With Rated Load)
  11kPa
• Maximum # of Persons (indoor/outdoor)
  2/1
• Tyre Type
  Solid, N/M
• Tyre Size
  12 x 4 x 8
