Skyjack 3219 Scissor Lift Electric

Detailed Description

• Drivable at full height with roll out deck fully extended
• Variable speed, front two wheel hydraulic drive
• 90° Steering (zero inside turning radius)
• Dual holding brakes
• Proportional controls for drive & lift functions
• 0.91 m Roll out extension deck
• 24V DC Power source
• Low voltage battery protection
• Relay-based control system
• SKYCODEDTM Colour coded and numbered wiring system ■ 30% Gradeability
• Solid rubber, non-marking tyres
• Pothole protection system
• Wiring for AC outlet on platform
• Tilt alarm with drive & lift cut-out
• Overload sensing system
• Lowering warning system
• Operator horn
• Half height spring hinged gate
• Hinged railing system
• Lanyard attachment points
• Forklift pockets and tie down/lift lugs

Available as self drive or with an optional professional machine operator.

Delivery & Collection: We always aim to deliver the machines at the time selected, although sometimes delays are inevitable. If delivery is selected for 10:00am, we will deliver any time from 07:30am depending on the delivery route. We will text or email you the day before to advise what time your machines will arrive. Collection will be made as soon as possible once you off hire the machines.

Cleaning: We will supply this machine clean. Please insure you clean the machine prior to us collecting after your hire is finished. Failure to clean the machine will result in cleaning costs.

Insurance: To book this machine you MUST have hired in plant insurance. These machines are very expensive but also very easy to steal. The insurance fee could be the best money you ever spend!

To get a free no-obligation insurance quotation please click  here

Technical Specification

• Manufacture
  Skyjack
• Model
  3219
• Work Height
  7.79 m
• Raised Platform Height
  5.79 m
• Lowered Platform Height
  0.99 m
• Overall Width
  0.81 m
• Overall Length
  1.78 m
• Stowed Height (Rails Up)
  2.10 m
• Stowed Height (Rails Down)
  1.75 m
• Platform Width (Inside Dimension)
  0.66 m
• Platform Length (Inside Dimension)
  1.63 m
• Extension Deck (Roll Out)
  0.91 m
• Ground Clearance (Stowed)
  6.03 cm
• Ground Clearance (Raised)
  1.78 cm
• Wheelbase
  1.40 m
• Weight
  1,312 kg
• Gradeability
  25%
• Turning Radius (Outside)
  1.68 m
• Lift Time (With Rated Load)
  25 sec
• Lower time (With Rated Load)
  29 sec
• Drive Speed (Stowed)
  3.1 km/h
• Drive Speed (Raised)
  1.1 km/h
• Maximum Drive Height
  Full Height
• Capacity (Overall)
  227 kg
• Distributed Capacity (Main Platform)
  114 kg
• Distributed Capacity (Extension Deck)
  113 kg
• Local Floor Load (With Rated Load)
  782 kPa
• Overall Floor Load (With Rated Load)
  11 kPa
• Maximum # of Persons (indoor/outdoor)
  2/1
• Tyre Type
  Solid, N/M
• Tyre Size
  12 x 4 x 8
